Coated type
D50 particle size: 0.7–1.6um
Specific surface area (SSA):≤16.00m2/g
Tap density:≥0.65g/cm3
(Coin Cell) Capacity:≥150.0mAh/g
(Coin Cell) ICE:≥88.0%
Product advantage
01 has long cycle life and high stability.
02 discharge platform can reach 1.55V, and the platform is very flat.
03 Li4Ti5012 is a kind of “zero strain material”, and lithium ion has good mobility and cycle performance.
High rate charge and discharge retention rate, excellent high and low temperature performance and high safety performance.
Application field:
ESS, hybrid electric vehicle, supercapacitor, special power supply.
Suggestions for use
1. Vacuum baking is required after opening, and it is not allowed to be exposed to air for a long time. Strict baking of LTO powder and electrode must have the process of heating, heat preservation and cooling.
2. With NMP system, conductive materials must be well dispersed and the volume of adhesive should be strictly controlled.
3. The electrode density is suggested to be 1.90~2.0 g/cc.
4. Slurry mixing is different from ordinary materials and should be stricter, otherwise it will affect the dispersion and quality of electrodes.
5, after folding the package, it is forbidden to directly contact with the human body or be affected with damp, to prevent the metal belt from oxidation, increase.
Welding difficulty and influence on electrical conductivity.
